TL431BID

regulator diode, 100mA, 36V, TO-92

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~0.16 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
300 ~ 500 :	0.16 / Piece
700 ~ 800 :	0.16 / Piece
900 ~ 1000 :	0.15 / Piece

PartNumber:: TL431BID

Brand:: Texas Instruments - TI | Pack: | D/C: 11+

Availability:: Supply Ability: 2500/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Ally's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-19

From Other Seller

Part Number:TL431BID
US $0.15 - 0.16
Quantity:

piece

Product Summary

The TL431BID is a programmable shunt regulator diode. The voltage references of the TL431BID operate as a low temperature coefficient zener which is programmable from Vref to 36V with two external resistors. The TL431BID exhibits a wide operating current range of 1.0 mA to 100 mA with a typical dynamic impedance of 0.22 Ω.

Parametrics

TL431BID absolute maximum ratings: (1) Cathode to Anode Voltage VKA: 37V; (2) Cathode Current Range, Continuous IK: -100 to +150mA; (3) Reference Input Current Range, Continuous Iref: -0.05mA to +10mA; (4) Operating Junction Temperature Tj: 150°C; (5) Operating Ambient Temperature Range: -40 to +85°C; (6) Storage Temperature Range Tstg: -65 to +150°C; (7) Total Power Dissipation @ TA=25°C, Derate above 25°C Ambient Temperature D, LP Suffix Plastic Package: 0.7W, P Suffix Plastic Package: 1.1W, DM Suffix Plastic Package: 0.52w; (8) Total Power Dissipation @ TC=25°C, Derate above 25°C Case Temperature, D, LP Suffix Plastic Package: 1.5w, P Suffix Plastic Package: 3.0W.
