LA7835

deflection output circuit, 15V, 8W, ZIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.23~0.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	0.30 / Piece
10 ~ 100 :	0.27 / Piece
100 ~ 1800 :	0.23 / Piece

PartNumber:: LA7835

Brand:: Sanyo Semicon Device - SANYO | Pack: ZIP | D/C: 02+

Availability:: Supply Ability: 1900/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Ally's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-16

From Other Seller

Part Number:LA7835
US $0.23 - 0.30
Quantity:

piece

Product Summary

The LA7835 is an IC that contains the vertical deflection output circuit with a driver for small-aperture (maximum deflection current 1.8Ap-p) color/B&W TV, monitor/display use and is placed in a SIP13H package. The LA7835 has such features as greatly reduced number of external parts and low power dissipation. The LA7835 can be used in conjunction with single-chip IC LA7650 (NTSC) , LA7680 series (PAL/NTSC) (VIF, SIF, video, chroma, and deflection circuit) to provide all the functions required for color TV signal processing.

Parametrics

LA7835 absolute maximum ratings: (1) driver power supply voltage +VCC1 max: 15V; (2) Pump-up power supply voltage +VCC7 max: 30V; (3) output power supply voltage +VCC12 max: 62V; (4) Deflection output current IDEF: -1.5V to +1.5V; (5) Allowable power dissipation Pd max: 8W (with infinite heat sink) ; (6) opertating temperature Topr: -20 to +85°C; (7) storage temperature Tstg: -40 to +150°C; (8) Thermal resistance: 4°C/W.

Features

LA7835 features: (1) Low power dissipation because of on-chip pump-up circuit; (2) On-chip 50/60Hz vertical size control circuit; (3) On-chip ramp generator; (4) On-chip driver circuit; (5) Vertical output circuit; (6) On-chip thermal protection circuit; (7) Minimum number of parts required.
