Product Summary
The AK4626VQ is a high performance multi-channel audio CODEC.
Parametrics
AK4626VQ absolute maximum ratings: (1)Power Supplies Analog: -0.3 V to 6.0 V; (2)Power Supplies Digital: -0.3 V to 6.0 V; (3)Power Supplies Output buffer: -0.3 V to 6.0 V; (4)Power Supplies |AVSS-DVSS|: 0.3 V; (5)Input Current (any pins except for supplies): ±10 mA; (6)Analog Input Voltage: -0.3 V to AVDD+0.3 V; (7)Digital Input Voltage(Expect LRCK, BICK pins): -0.3 V to DVDD+0.3 V; (8)Digital Input Voltage(LRCK, BICK pins): -0.3 V to TVDD+0.3 V; (9)Ambient Temperature (power applied): -40℃ to 85℃; (10)Storage Temperature: -65℃ to 150℃。
Diagrams
