Product Summary

The SN65LBC179DR differential driver and receiver pairs are monolithic integrated circuits designed for bidirectional data communication over long cables that take on the characteristics of transmission lines. The SN65LBC179DR is balanced, or differential, voltage mode devices that meet or exceed the requirements of industry standards ANSI RS-485 and ISO 8482:1987(E) . The SN65LBC179DR combines a differential line driver and differential line receiver and operate from a single 5-V supply.

Parametrics

SN65LBC179DR absolute maximum ratings: (1) Supply voltage range, VCC: -0.3V to 7V; (2) Voltage range at A, B, Y, or Z : -10V to 15V; (3) Voltage range at D or R: -0.3V to Vcc to +0.5V; (4) Continuous total power dissipation: internally limited; (5) Total power dissipation: See Dissipation Rating Table; (6) Operating free-air temperature range, TA: -40 to 85°C; (7) Storage temperature range, Tstg: -65 to 150°C; (8) Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260°C.

Features

SN65LBC179DR features: (1) Designed for High-Speed Multipoint Data Transmission Over Long Cables; (2) Operate With Pulse Widths as Low as 30ns; (3) Low Supply Current: 5mA Max; (4) Meets or Exceeds the Standard Requirements of ANSI RS-485 and ISO 8482:1987(E) ; (5) Common-Mode Voltage Range of -7 to 12V; (6) Positive- and Negative-Output Current Limiting; (7) Driver Thermal Shutdown Protection.

Diagrams

SN65LBC179DR Pin Configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SN65LBC179DR
SN65LBC179DR

Texas Instruments

Buffers & Line Drivers Lo-Pwr Diff Ln Drvr & Receiver Pair

Data Sheet

0-1790: $0.67
1790-2000: $0.64
2000-2500: $0.64
2500-5000: $0.61
SN65LBC179DRG4
SN65LBC179DRG4

Texas Instruments

Bus Transceivers Lo-Pwr Diff Ln Drvr & Receiver Pair

Data Sheet

0-1790: $0.67
1790-2000: $0.64
2000-2500: $0.64
2500-5000: $0.61
